FRONTEK PLUS and FRONTEK OMEGA PLUS kits, for ventilated external wall claddings, are composed by extruded ceramic tiles (FRONTEK and FRONTEK OMEGA), produced by GRUPO GRECOGRES INTERNACIONAL S.L., mechanically fixed to aluminum subframe.

The systems included in the ETA are:

• FRONTEK PLUS Horizontal Kit composed by extruded ceramic tiles FRONTEK mechanically fastened to an aluminium subframe by punctual fixings placed in the grooves of the cladding elements (family C);
• FRONTEK PLUS Vertical Kit composed by extruded ceramic tiles FRONTEK mechanically fastened to an aluminium subframe by punctual fixings placed in the holes of the cladding elements (family C);
• FRONTEK OMEGA PLUS Kit composed by extruded ceramic tiles FRONTEK OMEGA mechanically fastened to an aluminium subframe by punctual fixings placed in the grooves of the cladding elements (family C).

Families referred above are described in EAD 090062-01-0404: “Kit for external wall claddings mechanically fixed”, edition October 2021.

These kits can be fixed to the substrate wall of new or existing buildings. Usually on the substrate wall is also fixed the insulation material (defined in accordance with an EN standard or an ETA and is not manufactured by GRUPO GRECOGRES INTERNACIONAL S.L.

Kit for ventilated external wall claddings is non-load-bearing construction system. It does not contribute to the stability of the wall on which it is installed, neither to ensure the air tightness of the building structure but it can contribute to durability of the works by providing enhanced protection from the effect of weathering.
