The External Thermal Insulation Composite System (ETICS) “BEYEM-JAFEP” is a bonded system with supplementary mechanical fixings with EPS/XPS panel and mechanically fixed ETICS with supplementary adhesive on MW panel. The minimum number of fasteners per square metres is 6 for EPS/XPS/MW and 8 fasteners for building higher than 25m.
This ETICS is intended to be used as external thermal insulation for building walls. The walls are made of masonry (bricks, blocks, etc.), or concrete (cast on site or as prefabricated panels) with a reaction to fire classification A1 to A2-s2, d0 according to EN 13501-1 or A1 according to the EC decision 96/603/EC as amended. The ETICS is designed to give the wall to which is applied satisfactory thermal insulation.
This ETICS is made of non load-bearing construction elements. It does not contribute directly to the stability of the wall on which is installed, but it can contribute its durability by providing enhanced protection from the effect of weathering.
This ETICS can be used on new or existing (retrofit) vertical walls. It can also be used on horizontal or inclined surfaces which are not exposed to precipitation. The ETICS is not intended to ensure the airtightness of the building structure.
Product / System name:
Approval or assessment holder:
